Drop Side Wall Fence Semi Trailer
Size: 12480*2550* 2810（sidewall height 600mm) or customized
Tare weight: 6.5T
Payload: 40-70T
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of drop side wall fence semi trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved drop side wall fence semi trailer, welcome to get quotation from our factory.
Product Details
This 4-axle drop side fence trailer has a load capacity of 60 tons.
For drop side semi-trailers, the side wall structures include flat type and corrugated type. The side panels are available in 11-door and 13-door configurations. The standard side wall heights of the cargo body are 600 mm and 800 mm.
Product Parameters
Lead Time: According to quantity and seasons, the lead time is different.
|
Overall size(L*W*H)mm |
13000*2550*3800mm |
|
Material |
Q345B fabricated carbon steel |
|
Main beam |
Type: straight type; Height: 480mm; Upper plate: 14mm; Bottom plate: 16mm Middle plate: 8mm |
|
Rim |
22.5*9.0-14, 12 units |
|
King pin |
50# |
|
Platform |
3mm checker plate |
|
Twist lock |
12 units |
|
Landing gear |
28T |
|
Suspension |
Mechanical system with beams equaliser |
|
Axle |
Brand: Koree / Caree Capacity: 13T16P QTY: 4 units |
|
Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
|
Protectors |
Mudguard; Mud-flags behind rear axle; Mid & Rear Side protection; |
Our Company
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. has been focusing on trailer research and development, truck and related parts trade, engineering machinery sales, manufacturing and services since 2010. Our business scope not only covers the domestic market in China, but also expands to the global market according to local needs and special requirements
Our Advantages
1. Customizable sidewall height: The sidewall height can be customized to 600mm, 800mm, or 1000mm according to customer requirements.
2. Flexible axle configuration: 2, 3, or 4 axles can be provided to meet different load capacity requirements ranging from 60 tons to 100 tons
3. Advanced welding technology: automatic submerged arc welding and shot peening are used to improve the strength and durability of the beam.
FAQ
1. How about after-sales service?
A: We provide professional technical support and spare parts supply
2. Can you send spare parts?
A: Yes, we can supply original spare parts at any time.
3. What certificates do you have?
A: We have ISO, CCC, and can provide CO, FORM E, etc.
