20/40ft Flatbed Semi-trailer
Size:12400*2500*1510 or customizable Size
Tare weight: 7T
Payload: 30-80T
Material: Q355
Main beam: Height: 480mm; Upper plate: 14mm；
Bottom plate: 16mm;Middle plate: 8mm
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of 20/40ft flatbed semi-trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved 20/40ft flatbed semi-trailer, welcome to get quotation from our factory.
Product Details
We supply 20ft and 40ft flatbed semi-trailers, fabricated from high-strength low-alloy structural steel Q355B. Featuring superior resistance to deformation and cracking, these trailers facilitate convenient loading & unloading of diverse cargo including containers, timber, steel products and other bulk goods.
Product Parameters
|
Overall size(L*W*H)mm |
12400*2500*1510 |
|
Material |
Q355B/Q345B |
|
Main beam |
Type: straight type; Height: 480mm; Upper plate: 14mm; Bottom plate: 16mm Middle plate: 8mm Process: welded by automatic submerged-acr |
|
Side beam |
14#C type; Q235 |
|
Cross beam |
8# C type; Q235 |
|
plateform |
2-3mm checker plate |
|
Twist lock |
12 units |
|
Landing gear |
28T total Lifting capacity and 50T static capacity; double speed; large pad feet; JOST/China Brand |
|
Suspension |
Mechanical suspension(Germany or America type) or Air suspension(China brand or BPW brand) |
|
Axle |
Brand: BPW/FUWA/XINYA Capacity: 13T/16T QTY: 3 units |
|
Tyre |
Brand: chengshan/Triangle/Linglong; Type: 12R22.5-18PR; double mounted; QTY: 12 units |
|
Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
|
Tool box |
1 unit; include: 1 tyre spanner, 1 gudgeon sleeve & 1 cranking bar & instruction sheet |
Our Company
Our Advantages
Our flatbed semi-trailers feature outstanding versatility for wide-range industrial applications, capable of transporting containers ranging from 20ft to 53ft. The tare weight stands at 6.5~7 tons with a rated load capacity of 30~80 tons. Customization is available to meet clients' specific requirements.
The flatbed semi-trailer requires easy maintenance, cutting down maintenance expenses and maximizing the unit's profit-earning potential for operators.
FAQ
1.What after-sales service do you have?
We have a one-year warranty and provide 7 * 24-hour online support, as well as remote guidance, fault diagnosis, and solutions
2.How can we trust your company?
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. was founded in 2010 with 15 years of manufacturing and export experience. We are an integrated manufacturer combining production and trade, with an annual output of 4,000 to 5,000 semi-trailers.
3.What information do I need to provide if I want to get a quote?
Please provide detailed information, such as the size, tonnage, and type of cargo of the trailer, and we will provide you with the most accurate price information
4.How to ship
Choose the most suitable transportation method based on product type or size, such as sea freight, container, bulk cargo transportation, or Ro-Ro ship
