60CBM Dump Semi Trailer
Size: 11000*2500*3800mm or customized
Tare weight: 10T
Payload: 60T
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of 60cbm dump semi trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved 60cbm dump semi trailer, welcome to get quotation from our factory.
Product Details
The 60CBM Dump Semi Trailer can produce carriages of different shapes (rectangular, U-shaped, ship shaped, and specially reinforced) suitable for transporting different types of goods, such as large stones, crushed stones, sand, coal, grain, and other bulk goods.
Product Parameters
Lead Time: According to quantity and seasons, the lead time is different.
|
Overall size(L*W*H)mm |
11000*2500*3800mm |
|
Material |
Q345B/T700 |
|
Main beam |
Type: straight type; Height: 680mm; Upper plate: 14mm; Bottom plate: 16mm Middle plate: 8mm Process: welded by automatic submerged-acr |
|
Tyre |
12R22.5 |
|
Brake System |
Double line pneumatic braking system with WABCO emergency relay valve |
|
Lifting angle |
48–52° |
|
Landing gear |
28T total Lifting capacity and 50T static capacity; double speed; large pad feet; JOST/China Brand |
|
Suspension |
reinforced mechanical suspension |
|
Axle |
Brand: BPW/FUWA/XINYA Capacity: 13T QTY: 3 units |
|
Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
Our Company
Our Advantages
1. Customizable Box Shapes: Available in rectangle, U shape, ship shape, and special strong shapes for various bulk cargo.
2. Diverse Suspension Options: Equipped with leaf spring suspension or air suspension for enhanced stability.
3. Wide Color Selection: Any color is available upon request to meet specific customer preferences.
FAQ
1. Daily maintenance items?
A: Check hydraulic oil, fasteners, brake and lubricate moving parts.
2. Is air suspension available?
A: Yes, liftable air suspension is optional.
3. Does low temperature affect hydraulic system?
A: Use low-temperature hydraulic oil for normal operation.
