Extendable Flatbed Trailer
The dimensions of this three-axis extendable flatbed semi-trailer are 13700 * 2500mm
The extension length is 21 meters after being extended from 13 meters
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of extendable flatbed trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved extendable flatbed trailer, welcome to get quotation from our factory.
Product Details
This extendable flatbed semi-trailer is ideal for long steel rails, pipes and other lengthy cargo when fully extended. When retracted, it is suitable for transporting one 40ft container or two 20ft containers. It is equipped with 12 container twist locks.
Product Parameters
|
Overall size(L*W*H)mm |
13700*2500*1510 |
|
Material |
T700 high-strength steel |
|
Main beam |
Type: straight type; Height: 480mm; Upper plate: 12mm; Bottom plate: 14mm Middle plate: 8mm Process: welded by automatic submerged-acr |
|
plateform |
4mm checker plate |
|
Twist lock |
12 units |
|
Landing gear |
28T total Lifting capacity JOST/China Brand |
|
Suspension |
Mechanical suspension(Germany or America type) or Air suspension(China brand or BPW brand) |
|
Axle |
Brand: BPW/FUWA/XINYA Capacity: 13T/16T QTY: 3 units |
|
Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
|
Brake system |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber;Two 40L air tanks, ABS Optional |
|
Tyre |
Brand: chengshan/Triangle; double mounted; QTY: 12 +1units |
Our Company
Our Advantages
1.The main beams of the extendable trailer are made of T700 high-strength steel.
2.FUWA heavy-duty mechanical suspension
3.Fitted with well-known brand components: FUWA axles, FUWA leaf springs, WABCO braking system and JOST landing legs.
FAQ
Q: What is your surface treatment process?
A: We adopt sand blasting, followed by one coat of anti-corrosion primer and two coats of top paint.
Q: Which countries do you mainly export to?
A: We export to over 50 countries, including Tanzania, Zambia, Kenya, Zimbabwe, Nigeria, Malaysia, Australia, Ghana and Mexico.
Q: Can we print our company logo on the trailer?
A: Of course, we can customize the icon and brand image according to your requirements
