4 Axle Tipper Semi Trailer
Factory Price Heavy-Duty 3-Axle Dump Semi Trailer Rear U Shape Dump Truck Semi Trailer 40 Cubic Meter Tipper Trailer for Sale
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of 4 axle tipper semi trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved 4 axle tipper semi trailer, welcome to get quotation from our factory.
Product Details
The rear dump semi trailer adopts rear-dump self-unloading methods, which improves the efficiency of the bulk cargo transport by the loader. The dump trailer is inclined at a certain angle so that the cargo in the carriage is unloaded. The rear tipping semi trailer uses 4 turn over brackets, which makes the cargo box body more strong.
Product Parameters
|
Size |
9968mm*2500mm*3566mm |
|
Payload |
30-80T |
|
Main beam |
Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-Arc processes. Top flange 18mm,width140mm;Middle Flange 14mm height 500mm;bottom flange20mm,width 140mm |
|
Floor |
8mm checkered plate (Optional) |
|
Side wall |
Height 1600mm thickness 6mm (Optional) |
|
Cylinder |
HYVA (Optional) |
|
Axle |
4 axle FUWA brand 13T (Optional) |
|
Suspension |
Mechanical suspension American type (Optional) |
|
Leaf spring |
Leaf spring 10pcs*90*13mm (Optional) |
|
Tire |
12R22.5 16pcs (Brand and specs optional) |
|
Wheel rim |
9.0-22.5 16pcs (Brand and specs optional) |
|
Kingpin |
2"/3.5" bolt-in /welded king pin |
|
Landing gear |
Two-speed, manual operating ,heavy duty landing gear 28T |
|
Braking system |
WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
|
ABS |
Optional Customer can choose china brand or WABCO brand or without ABS |
|
Light |
LED 8 side lights and 2 rear lights 2 width lamp |
|
Painting |
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
|
Accessories |
One standard tool box,one spare tire carrier,one crank,one shaft head wrench,four side light,two rear light |
Our Company
Our Advantages
1. Strengthen the main beam, crossbeam, and box shaped body to enable our rear dump semi-trailer to adapt to various road conditions.
2. Heavy duty high-strength I-beam, durable and long-lasting; High strength Q345 steel is selected and welded using automatic submerged arc welding technology. The upper flange has a thickness of 18mm and a width of 140mm; the middle flange has a thickness of 14mm and a height of 500mm; and the lower flange has a thickness of 20mm and a width of 140mm.
3. The dump semi-trailer carriage can be selected in square or U-shaped. The square carriage has the strongest load-bearing capacity, while the U-shaped carriage has the weakest load-bearing capacity.
FAQ
1. What payment methods do you support?
- We support T/T and LC and other ways you need.
2. What is your minimum order quantity?
- One unit.
3. How about the delivery time?
- Generally it will takes 10 to 30 days after receiving your deposit. The specific date will be depended on your order and item. We will contact you if we confirm the delivery date. And we will track the goods all the time until the goods reach to the destination.
4. What can you provide me?
-One-year warranty, maintenance personnel can go abroad for repairs, free accessories and models.
5. How can I confirm whether your products will meet my needs?
-You can tell us your needs such as size, material, volume, height and other information, our professional sales will provide solutions, and we supply OEM services.
