Tri Axle Flatdeck Semi-trailer
This 3-axle flatbed semi-trailer is fitted with 12 container twist locks, 24 lashing winches, FUWA landing gears and 12 pieces of tires.
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of tri axle flatdeck semi-trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved tri axle flatdeck semi-trailer, welcome to get quotation from our factory.
Product Details
This flatbed model features an open flat loading deck. Front bulkhead and removable stakes are available as optional fittings.
It has versatile applications for transporting 20ft/40ft/45ft containers, bulk goods and oversized cargo.
Product Parameters
|
Overall size(L*W*H)mm |
12400*2500*1510 |
|
Material |
Q345B fabricated carbon steel |
|
Main beam |
Type: straight type; Height: 480mm; Upper plate: 14mm; Bottom plate: 16mm Middle plate: 8mm Process: welded by automatic submerged-acr |
|
plateform |
2-3mm checker plate |
|
Twist lock |
12 units |
|
Landing gear |
Standard 28Ton, JOST brand or FUWA |
|
Suspension |
Mechanical suspension |
|
Leaf Spring |
90*13-10 4/6/8 sets, Funiu ocTaiyue etc. |
|
Axle |
Brand: BPW/FUWA/XINYA Capacity: 13T/16T QTY: 3 units |
|
Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
|
Brake system |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber;Two 40L air tanks, ABS Optional |
Our Company
Our Advantages
1. The main beam is optional using Q355/Q345/T700 steel
2. This model is generally straight beam type, less will choose gooseneck type
3. Car bridge brand optional; FUWA/BPW/CAREE
4. Factory direct sales, provide stable high quality semi-trailer
FAQ
Q: What's your after-sale service?
A: Our quality warranty period is one year. Any quality problem will be solved to customer satisfactions
Q:.How long will our price be valid?
A: Price with long valid time We only adjust our price based on two factors: the changes of the international currency exchange rates and the rising in price of labor and row material.
