Platform Semi Trailer
Overall size(L*W*H)mm: 12400*2500*1510
Type: straight type
Tare weight: 6.5-7T
Payload: 30-60T
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of platform semi trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved platform semi trailer, welcome to get quotation from our factory.
Product Details
Custom flatbed semi-trailers are available. This model comes without side stakes and features a full flat loading platform. A front headboard is optional, and plug-in side stakes can be fitted on both sides upon request. It is suitable for hauling bulk goods, oversized cargo and standard containers.
Product Parameters
|
Overall size(L*W*H)mm |
6200 /12480mm*2500mm*1520mmor customized size |
|
Material |
Q345B fabricated carbon steel |
|
Main beam |
Beam height 500 mm, Upper plate 14 mm, Down plate 16 mm: Middle plate 6/8 mm |
|
plateform |
3mm checker plate |
|
Twist lock |
4 pcs or 8 pcs or 12 pcs container lock |
|
Landing gear |
28T total Lifting capacity and 50T static capacity; double speed; large pad feet; JOST/China Brand |
|
Suspension |
Mechanical suspension(Germany or America type) or Air suspension(China brand or BPW brand) |
|
Axle |
Brand: BPW/FUWA/XINYA Capacity: 13T/16T QTY: 2/3/4pcs, |
|
Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
|
Brake system |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber;Two 40L air tanks, ABS Optional |
Our Company
Our Advantages
- The complete vehicle comes with a one-year warranty and is backed by a professional after-sales service team.
- Our factory is equipped with a full range of intelligent manufacturing equipment, including automatic laser cutting machines, robotic welding systems, and automated painting production lines.
- The main beam is manufactured from high-strength steel, featuring uniform welds, excellent load-bearing stability, and outstanding durability.
- Factory-direct sales ensure competitive pricing. Every trailer is delivered with a Product Quality Inspection Certificate before leaving the factory.
FAQ
Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, America, this help us better know have to handle with different certificates needed.
Q: How about warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.
Q: Which markets do you export your car to?
A: We export flatbed trailers, side wall trailers, fence trailers, dump trucks, dump truck trailers, and low bed trailers to various parts of the world, especially in the African and Southeast Asian markets. Our customers come from Djibouti, Ghana, Mozambique, Mauritania, Tanzania, Benin, Indonesia, Malaysia, Kenya, and more.
