Standard Flatbed Semi Trailer
Flatbed semi-trailers are highly popular models. Featuring versatile application and low maintenance costs, they are suitable for transportation across various industries.
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of standard flatbed semi trailer in China, featured by high quality customized service and OEM service. If you're going to buy CE approved standard flatbed semi trailer, welcome to get quotation from our factory.
Product Details
This 3-axle flatbed semi-trailer can carry one 40ft container or two 20ft containers.
All 3-axle 40ft flatbed trailers can be custom-designed according to your requirements, load capacity and overall dimensions.
Product Parameters
Lead Time: According to quantity and seasons, the lead time is different.
|
Overall size(L*W*H)mm |
12400*2500*1510 |
|
Material |
Q345B/Q355B/T700 |
|
Main beam |
Type: straight type; Height: 480mm; Upper plate: 14mm; Bottom plate: 16mm Middle plate: 6/8/10mm Process: welded by automatic submerged-acr |
|
plateform |
2/3mm checker plate |
|
Twist lock |
4 pcs or 8 pcs or 12 pcs container lock |
|
Landing gear |
Standard 28Ton, JOST brand or FUWA |
|
Suspension |
Mechanical Suspension / air suspension / single point suspension (Germany Type or America Type or Japan Type) |
|
Axle |
Brand: BPW/FUWA/XINYA Capacity: 13T/16T QTY: 3 units |
|
Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
|
Brake system |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber;Two 40L air tanks, ABS Optional |
Our Company
Our Advantages
- Our flatbed semi-trailers are manufactured from high-strength steel: Q345B, Q355B and T700.
- Adopting automatic submerged-arc welding (SAW), the welds are firm and well-formed with excellent shock and impact resistance.
FAQ
1.How to ensure product quality
We have successively passed ISO9001, IATF 16949, ISO14001, ISO45001 certification systems, as well as CCC mandatory product certification
Each trailer comes with a product quality certificate before leaving the factory
2.Can I visit your factory?
Of course, we welcome customers from all over the world to visit our factory and inspect our production process
3.How can I obtain a quotation
Please provide detailed information such as trailer type, size, load capacity, and road conditions
Hot Tags: standard flatbed semi trailer, China standard flatbed semi trailer manufacturers, suppliers, factory
